7" COLOR Rear View Backup Camera System - LCD Mirror Monitor + Keyhole CCD Camera

$129.99

Product Information

VEHICLE REAR VIEW BACKUP SYSTEM - CCD COLOR  INFRARED NIGHT VISION KEYHOLE CAMERA WITH 7" TFT LCD REAR VIEW MIRROR MOUNT MONITOR!!!

THE SIMPLEST INSTALLATION SOLUTION!!!

The TFT LCD Rear View Mirror Monitor Also Works With Our Many Other Addtional Rear View Cameras! Up to TWO Cameras Can Be Viewed On The 7" Wide Screen Monitor Within The Mirror!

Added Bonus!!!

Free 32' Cable to connect the monitor to the camera.  Normally sold separately, this MSRP's for $30.  You don't have to shop elsewhere!!!  We're giving it to you for free as thanks for purchasing the camera/monitor set.  Depending upon your needs we also sell a longer 49' cable at additional $10.

When You Purchase Through Us This Is What You'll Get

  • One CCD COLOR Keyhole Weather/Water-Proof Wide Angle Vehicle Rear View Camera With Wide View Angle, and Infrared Night Vision (Model CW134085CI, black color).  Approx. ? 1.2" x 1.9" for cylinder part. Camera comes with angle control rings, fix ring, RCA video output socket, and power input.
  • All the necessary cable hookups and Male Power Lead Plug to get your camera up and running.
  • One (1) NEW Rear View Mirror 7" Diagonal Viewing Surface COLOR Monitor
  • One (1) Remote Controller
  • All the necessary cable hookups for monitor installation and right out-of-the-box use.
  • 32' or 49' cable to connect the backup camera and rear view mirror monitor, with heavy duty weatherproof connectors!!!
  • English user manual for both CCD Camera and TFT LCD Monitor



Camera Cable Connectors

Camera Cable Connectors

(Stock Photo Provided By Manufacturer)

Camera Cable Connectors

Front Panel Control with On-Screen Menu

Camera Cable Connectors

Universal Adjustable Mounting Clips to Attach Monitor to Existing Rear View Mirror in Seconds

Camera Cable Connectors

Connection Diagram, Manufacturer Stock Photo

Camera Cable ConnectorsCamera Cable Connectors

Clip-on the original mirror
Manufacturer Stock Photo



Camera Cable Connectors

 Camera Cable Connectors





The CCD Camera Has The Following Special Features

  • Durable, rustproof stainless steel bodied KEY HOLE camera with FLUSH MOUNT
  • Water-proof without extra housing: for part (camera glass lens) exposed to outside ONLY and for normal usage ONLY. Camera body and cables are not designed to be exposed to outside and must be properly sealed against moisture. Incorrect installation and using the product in opposition to the manufacturer's instructions MAY result in loosing water-proof feature.
  • CCD color, 1/3" CCD image sensor
  • High power, over launch infrared tubs - auto activate at night
  • High resolution 420 TV Lines
  • Low illumination requirement - 0 LUX (w/LEDs on)
  • User adjust left/right mirror reverse image - can set to display a reversed camera image on the monitor (for vehicle rear viewing to duplicate the normal view seen in a rear-view mirror) OR a normal view on the monitor (for vehicle front viewing) - connect two-pin jumper connector to the mirror reverse wire to set for normal view
  • 120 Degree Wide Angle View - Essential to get a wide picture view especially when backing up a towed vehicle or a vehicle with wide turning radius
  • Standard RCA video output - When in need of replacement cables you can simply buy them off the shelves of any store selling video cables.  There's no need to shop around for some "special type" of cable.  The connectors are compatible with this product as they would be with any VCR, DVD player, TV, or Monitor.
  • Uses standard 12V DC power supply found in most land vehicles
  • Caution: The camera is designed to operate within a range of constantly changing voltage levels produced by a vehicle's battery and alternator (post engine ignition) under normal use conditions. Some vehicles have a very high momentary voltage at the vehicle starting time and the excessive voltage generation at that time might cause damage to the camera. If your vehicle tends to emit high voltage levels during ignition you will need to install a fuse/voltage regulator/etc. to protect your camera. Please consult with a professional vehicle audio/video equipment installers if needed.

Model CW134085CI Technical Specifications

CW134087CAI Rear View Camera Dimension
(Stock Photo Provided By Manufacturer)
Approx. 1.2" x 2.5" for cylinder part
Image Sensor 1/3" SHARP CCD Sensor Horizontal Resolution 420 TV Lines
Effective Pixels 512(H) x 492(V) Minimum Illumination 0 LUX (w/IR LEDs on) / F:2.0
Sensing Area 4.9mm x 3.7mm Sync System Internal
Horizontal Sync Frequency 15,734 KHz Vertical Sync Frequency 60 Hz
Scanning System 1/2 Interlace Gamma Consumption 0.45
Video Out Signal 1.0 Vp-p 75 ohm Power Supply DC 12V
AGC Auto S/N Ratio Better than 48dB
Electronic Shutter 1/60 - 1/100,000 second Weight Approx 50 g
Dimensions 31 mm x 64 mm (approx. 1.2" x 2.5") Built-in Lens f=2.8mm / F=2.0
Cable Output Standard RCA Video (Yellow) & DC (Red) Jack BLC Auto
White Balance Auto TV System NTSC
Operating Temperature -4°F - 158°F (-20°C - 70°C) / RH 95% Max Storage Temperature -40°F - 176°F (-40°C - 80°C) / RH 95% Max
Current Consumption Max 200mA Lens Angel Wide View Angel 120°

The TFT LCD Monitor Has The Following Special Features

Monitor Technical Specifications

    • Has Both Front Panel On-Screen Menu and Wireless Remote Control
    • Fits most standard factory installed and after market rear view mirrors. Slot device simplifies installation and detachment
    • Special optical lens substitute the original Back-view Mirror
    • Standard RCA Video hookups
    • Automatically shift back-view system when reversing the car
    • Reverse Image Switch - Automatically wake up reversing back-view display
    • Up to TWO cameras can be viewed on the 7" wide screen monitor within the mirror!
    • Blue color background automatically appears when video signal disappears
    • Can be used as a normal Rear View Mirror when the Monitor is off
    • Universal adjustable mounting clips to attach the monitor over your existing rear view mirror in seconds!


CW134087CAI Rear View Camera Dimension
(Stock Photo Provided By Manufacturer)
Approx. 10.2" (w) x 4.2" (h)
Dimensions shown are approximate and for demonstration only, actual dimensions may be slightly different.

Display Screen 7" Color TFT Resolution 234xRGBx480 pixels
Aspect Ratio 16:9 Contract Ratio 300:1
TV System NTSC/PAL Auto Switch Power Supply DC 12V
Power Consumption 7 Watts MAX

Working Environment

-20°C - 65°C (-4°F - 149°F)
Definition 1440(W) x 234(H) Display Function Auto Reversing Back-View Shift (Mirror)
Monitor Size w/ Rear View Mirror Frame  Approx. 260mm x 106mm x 30mm
(10.2" x 4.2" x 1.2")

Weight(monitor only)

Approx. 17.6 oz (1.1 pounds)
NOTE: Fits most standard and after market rear view mirrors.

Please confirm that yours is the right size prior to purchasing.  Please ensure that the mirror can withstand the weight.


Install Rear View Backup System

CW134087CAI Rear View Camera Dimension
Stock Photo Provided By Manufacturer



Product Code: YT700HCW085
